NAP250 MOD 2SC5200 미니 스테레오 파워 앰프 베이스, 영국 NAIM 회로, SPK 보호, 80W + 80W 8R
상품 정보
여러분께 소개할 이 제품은 NAP250 MOD 2SC5200 미니 스테레오 파워 앰프 베이스으로, 여러분의 생활을 더욱 편리하고 풍요롭게 만들어 줄 것입니다. 아래에서 제품의 특징, 사용 방법, 그리고 왜 이 제품이 여러분에게 이상적인지에 대한 상세한 정보를 제공하겠습니다. 정성껏 준비한 상품 설명을 통해, 여러분이 필요로 하는 최적의 선택을 할 수 있도록 도와드릴 것입니다.
Introduction:
NAIM NAP250 MOD is base on the famous NAIM NAP250, Better performance than NAIM NAP140 /200, and the price is cheaper.
NAP250 MOD using MINI circuit board design, reducing the length of PCB wiring, While also reducing the impact of PCB wiring resistance.
PCB copper wire shorter, the smaller the resistance, the performance will be improved. In addition NAP250 MOD version of the original modified some BUG. So that the temperature compensation tube can be installed with the high-power tube in the same radiator.
So that the NAP250 MOD can work in CLASS AB. To avoid the cross-distortion.
Main materials:
◆ 500W high power amplifier dedicated switching power supply to ensure adequate power.
◆ Original power transistor ST 2SC5200.
◆ Full aluminum chassis + Stainless steel switch, Feel first class.
◆ The machine has a perfect speaker protection circuit.
◆ High-quality copper output terminals.
Input voltage: AC 115V or 230V (Optional)
Suitable for Impedance: 4 --- 8 ohm
Size: 170×60×292mm (W*H*D)
Weight: 2.5KG
Output power: RMS 80W+80W 8 ohm
Current: About 10-20 mA
THD+N: 0.001% -0.03% (20HZ-20KHZ 5W-30W 8OHM Audio Precision 2 TEST)
Frequency response: 20Hz -0.04dB, 20KHz -0.34 dB, 15Hz -0.05dB, 30K Hz -52dB
NOTE: We have two versions and front panel color options, the pure power amplifier version and the version with volume control. You can choose the version and color you like. We do not provide any cables.
